Description
This 750W integrated servo motor has a 80mm frame size and is integrated with 17-bit encoders and servo drives. This model has a electromechanical brake. Voltage range 24-60VDC.
The iSV2-RS8075V48G product is an integrated servo motor with peak torque to 7.2 Nm. Additionally the compact size the iSV2 can save mounting space, eliminate encoder and power cable connections and reduce system cost.
● Main power voltage: 24-60VDC. Rated voltage: 48VDC
● Rated power: 750W. Rated torque: 2.39N.m. Overload: 300%
● 17 bit incremental magnetic encoder
● Pulse+Direction
● Modbus RTU over RS485. Build-In 16 PR paths
● Dip switch for node ID, baud rate and terminating resistor settings
● RS-232 serial interface for easy tuning with Motion Studio
● With brake
| Model | iSV2-RS8075V48G |
| Frame size (mm) | 80 |
| Rated power (W) | 750 |
| Rated voltage (VDC) | 48 |
| Rated torque (Nm) | 2.4 |
| Rated current (Arms) | 19 |
| Rated speed (r/min) | 3000 |
| Peak torque (Nm) | 7.2 |
| Maximum current (Arms) | 57 |
| Maximum speed (r/min) | 4000 |
| Encoder | 17 bit incremental magnetic encoder |
| Weight (kg) | 3.19 |
| Protection class | IP20 |
| Communication | Modbus RTU |
750W integrated servo motor certification: iSV2_CE-EMC_CERTIFICATE
2D Drawing download: iSV2-RS8075V48G 2D Drawing
3D drawing download (LeadShine Website): Click here
Manual Download (LeadShine Website): Click here
Software Download (LeadShine Website): Click here
