Description
● No loss of step & no torque reservation & no hunting & no tuning.
● Enhance performance, especially at low-speed application (<60RPM).
● Auto-tuning to match wide-range NEMA 23, 24 and 34 closed-loop stepper motors.
● Max 500 KHz input frequency.
● 15 micro step settings of 800-51,200 via DIP switches, or 200-51,200 via software.
● 2 out current settings and gain tuning via S1 rotating switch.
| Model | CS-D1008E |
| Series | CS |
| Command Source | PUL&DIR, CW&CCW |
| Operation Voltage (VDC) | 18-80VAC or 30-110VDC |
| Output Current (A, Peak) | 8.0 |
| Input Frequency (KHz, Max.) | 500 |
| Logical Voltage (VDC) | 5 or 24 |
| # of Inputs | 3 |
| # of Outputs | 2 |
| Characteristics | Standard |
User manual: here
3D model: Click here (Leadshine Website)
