Description
| Output voltage | 48 V |
| Power boost ratio | 120 % |
| Rated output current | 10 Amp |
| Display | No |
| Low-voltage detection output | No |
| Overload protection | Yes |
| Overvoltage protection | Yes |
| Parallel operation | Yes |
| Power boost | Yes |
| Preventive maintenance alarm output | No |
| Product Height (unpacked) | 125 mm |
| Product Depth (unpacked) | 140 mm |
| Product Width (unpacked) | 95 mm |
| Allowable supply voltage AC | 85-264 V |
| Allowable supply voltage DC | 90-350 V |
| Temperature range | -40-70 °C |
| Efficiency | 93 % |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | -40 °C |
| Numeric of output branches | 1 |
| Series operation | Yes |
| Alarm function | – |
| Communication port(s) | None |
| EMI class | Class B |
| Mounting method | DIN rail |
| Phase | Single |
| Terminal | Screw |
| Type | Book type |
| Wiring type | Rise-up |
