Description
The 200W AC servo motor are designed by Leadshine. The servo motors use permanent magnet rotors which provide features of high torque density, high peak torques, low noise, low temperature rising and lower current consumption. The motors power range from 50W to 1000W, frame size range from 40mm to 80mm.
- Rated voltage 220VAC, rated power 200W
- Frame 60mm, rated torque 0.64N·m, rated speed 3000r/min
- 23-bit optical encoder
- No brake, direct connector
- Strong overload capacity
- IP67
| Model | ELM2H-0200LA60F |
| Frame Size (mm) | 60 |
| Rated Voltage (Vac) | 220 |
| Rated Power (W) | 200 |
| Rated Torque (N.m) | 0.64 |
| Peak Torque (N.m) | 1.92 |
| Rated Speed (rpm) | 3000 |
| Peak Speed (rpm) | 5000 |
| Rated Current (Amp) | 1.5 |
| Peak Current (Amp) | 4.8 |
| Torque Constant (N.m/Amp) | 0.447 |
| Back EMF Constant (V/krpm) | 27 |
| Resistance (Ω) | 6.8±10% |
| Inductance (mH) | 16.7±20% |
| Inertia (kg*m2*10-4) | 0.28 |
| Poles | 10 |
| Encoder Type | 23bit optical |
| IP Rating | IP67 |
| Weight (Kg) | 0.95 |
200W AC servo motor 2D Drawing download: ELM2H-0200LA60F
3D drawing download (LeadShine Website): Click here
Certification Download (LeadShine Website): Click here
