0.4N.m, 1.5A, NEMA 17 stepper motor CS-M21704 – 62mm long
The CS-M series closed loop stepper motors are integrated with a 1,000 line (4,000 counts/revolution) or 5,000 line (20,000 counts/revolution) differential ended rotary encoder. NEMA 17 stepper motor is 62mm long with a 1.5A phase current. Build with high quality materials including bearings and shaft made by famous manufacturers, this closed loop stepper motor can…
-
0.6N.m, 2.5A, NEMA 17 stepper motor CS-M21706 – 70mm long
The CS-M series closed loop stepper motors are integrated with a 1,000 line (4,000 counts/revolution) or 5,000 line (20,000 counts/revolution) differential ended rotary encoder. NEMA 17 stepper motor is 62mm long with a 1.5A phase current. Build with high quality materials including bearings and shaft made by famous manufacturers, this closed loop stepper motor can…
-
1.3N.m, 4.0A, NEMA 23 stepper motor – CS-M22313 – 72mm long
The CS-M series closed loop stepper motors are integrated with a 1,000 line (4,000 counts/revolution) or 5,000 line （20,000 counts/revolution） differential ended rotary encoder. Built with premium quality materials including bearings and shaft, this closed loop stepper motor can be adopted in many industrial applications. Such as; high precision, low motor heating, and low vibration.…
-
12N.m, 6A, Nema 34 stepper motor CS-M234120 – 158mm long
2 phase, NEMA 34 frame size 158 mm (6.22 inch) long 6 A phase current 12 N.m (1700 oz-in) holding torque 14 mm (0.551 inch) shaft size Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder High precision, low motor heating, and low vibration
-
3-phase hybrid stepper motor – 573S15-L
The 3S series are 3-phase hybrid stepper motors, can be implemented in many industrial motion control applications. Built with premium quality materials. The 573S15-L can move the attached load at high precision and with very low motor heating and vibration. ● 3 phase 1.2° stepping angle ● Standard NEMA 23 dimensions ● Holding torque of…
-
4.0A NEMA 23 stepper motor – 57CM13-0-I8
Built with premium quality materials including bearings and shaft, the 57CM13-0-I8 NEMA 23 can move the attached load at high precision with very low motor heating and vibration. 2 phase, NEMA 23 frame size 55 mm (2.17 inch) long 4 A phase current 1.3 N.m (185 oz-in) holding torque 8 mm (0.315 inch) shaft size…
-
4.5N.m, 6A, NEMA 34 – stepper motor CS-M23445 – 109mm long
2 phase, NEMA 34 frame size 109 mm (4.29 inch) long 6 A phase current 4.5 N.m (638 oz-in) holding torque 14 mm (0.551 inch) shaft size Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder High precision, low motor heating, and low vibration 2D drawing download: here 3D Step file download: here
-
400w integrated servo motor – iSV2-RS6040V48H – LeadShine
We have implemented about 80 of these servo motors in the last few years, they are a great, easy to use, reliable servo with so many features! This Leadshine iSV2-RS6040V48H is a 60mm integrated servo motor. At a very compact size an iSV2 integrated servo motor can save mounting space, eliminate encoder & power cable…
-
42CM02, NEMA 17, 33 mm, 1.5A, 0.21 N.m
Leadshine 2 phase, NEMA 17 stepper motor 33 mm (1.30 inch) long 1.5 A phase current 0.21 N.m (30 oz-in) holding torque 5 mm (0.197 inch) shaft size Built with high quality materials including bearings and shaft made by Japanese manufacturers High precision, low motor heating, and low vibration 2D drawing: 42CM02 3D CAD file:…
-
42CM08C, NEMA 17, 60 mm, 2.5A, 0.8 N.m
2 phase, NEMA 17 frame size 60 mm (2.36 inch) long 2.5 A phase current 0.8 N.m (113 oz-in) holding torque 5 mm (0.197 inch) shaft size Built with high quality materials including bearings and shaft made by Japanese manufacturers High precision, low motor heating, and low vibration 2D drawing: 42CM08C 3D CAD file: 42CM08C
-
5.0A NEMA 23 stepper motor – 57CM26
Built with premium quality materials including bearings and shaft, the 57CM26 NEMA 23 can move the attached load at high precision with very low motor heating and vibration. 2 phase, NEMA 23 frame size 84 mm (3.31 inch) long 5 A phase current 2.6 N.m (369 oz-in) holding torque 8 mm (0.315 inch) shaft size…
-
57CM13, NEMA 23, 55 mm, 1.3 N.m Leadshine
2 phase, NEMA 23 frame size 55 mm (2.17 inch) long 4 A phase current 1.3 N.m (185 oz-in) holding torque 6.35 mm (0.25 inch) shaft size Built with high quality materials including bearings and shaft made by Japanese manufacturers High precision, low motor heating, and low vibration
-
57CM23-SZ NEMA 23, Dual 8mm shaft, 2.3 N.m
Dual Shaft Stepper. 2 phase, NEMA 23 frame size 76 mm (2.99 inch) long 5 A phase current 2.3 N.m (326 oz-in) holding torque 8 mm (0.315 inch) shaft size Built with high quality materials including bearings and shaft made by Japanese manufacturers High precision, low motor heating, and low vibration
-
6.0A NEMA 34 stepper motor – 86CM80-0-I14
Built with premium quality materials including bearings and shaft. The 86CM80-0-I14 NEMA 34 can move the attached load at high precision with very low motor heating and vibration. 2 phase, NEMA 34 frame size 98 mm (3.86 inch) long 6 A phase current 8 N.m (1133 oz-in) holding torque 14 mm (0.55 inch) shaft size…
-
8.5 N.m, 6A closed loop stepper motor CS-M23485, 147mm long
2 phase, NEMA 34 frame size 147 mm (5.79 inch) long 6 A phase current 8.5 N.m (1204 oz-in) holding torque 14 mm (0.551 inch) shaft size Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder High precision, low motor heating, and low vibration
-
86CM120C NEMA 34, CM series stepper motors 129mm, 12 N.m, LeadShine
2 phase, NEMA 34 frame size 129 mm (5.08 inch) long 6 A phase current 12 N.m (1700 oz-in) holding torque 14 mm (0.551 inch) shaft size Built with high quality materials including bearings and shaft made by Japanese manufacturers High precision, low motor heating, and low vibration
